Name

c channel steel roll forming machine

Raw material

Galvanized

Thickness

0.3-0.8mm

Inner Diameter

450-550mm

Max Coil width

300mm

Capacity

1.5T

Forming steps

10 rollers 10rollers

Shaft diameter

40mm

Design type

Memorial arch

roller material

GCr12MoV steel

shaft material

45# steel

Work speed

0-25m/min

Transport

By gear

Power of main machine

5.5kw

Type of cutting

Hydraulic

Cutting tolerance

±1mm

Cutter

Gcr12

Hydraulic oil

46#

Hydraulic power

3kw

PLC Brand

Delta(as your requirement)
